Description：
Model: TSRP-HP45-360
Material: red copper fins + brass water chamber flat tube + steel guard plate
Hole position: G1/4 thread *5
Size: 394mm* 120mm* 46.85mm
Capacity: about 280ml (manual measurement, slight error)
Pressure test: 1bar(Please note: it is recommended not to exceed this pressure value during use, which may cause damage risk)
Suitable fan: 12cm fan
Number of pipes: 12 in single layer, 24 in total in 2 layers
Heat dissipation area: 1.19 square meters
Surface treatment: Spraying
Welding agent: environmentally friendly tin complies with ROHS 2.0
Packing list:
Copper radiator *1pcs
End plug*3 pcs(installed)
Screw*24（Thread 6#-32, long screw length 31mm, short screw length 9mm）
